Model No.: T-319A(-50~400°C), T-319B(-50~600°C)
Features:
Overview and application
This infrared thermometer consist of optics, temperature sensor signal amplifier, processing circuit and LCD display. It is used for quickly and safely measuring the temperature of the object's surface without contact ,especially for which are various hot, hazardous or hard-to-reach.
Technical data
|
Temperature range |
T-319A: -50~400°C (-58~752°F) T-319B: -50~600°C (-58~1112°F)
|
|
Accuracy |
<0°C(32°F): ±3°C(±5°F); >0°C(32°F):,±1.5°C(±2.7°F) or ±1.5% whichever is greater |
|
Repeatability |
1% /1°C |
|
Emissivity |
0.95 preset |
|
Distance to spot (D:S) |
12:1 |
|
Respond time |
500ms,95% response |
|
Spectral respond |
5~14um |
|
Operation temperature |
0~40°C(32~104°F) |
|
Operation humidity |
10~90% RH non-condensing,up to 30°C |
|
Storage temperature |
-20~60°C |
|
Power supply |
1.5V AAA*2 |
|
Typical battery life |
12 h with laser off |
Image description:
|
Temperature range |
T-319A: -50~400°C (-58~752°F) T-319B: -50~600°C (-58~1112°F) |
|
Accuracy |
<0°C(32°F): ±3°C(±5°F); >0°C(32°F):,±1.5°C(±2.7°F) or ±1.5% whichever is greater |
|
Repeatability |
1% /1°C |
|
Emissivity |
0.95 preset |
|
Distance to spot (D:S) |
12:1 |
|
Respond time |
500ms,95% response |
|
Spectral respond |
5~14um |
|
Operation temperature |
0~40°C(32~104°F) |
|
Operation humidity |
10~90% RH non-condensing,up to 30°C |
|
Storage temperature |
-20~60°C |
|
Power supply |
1.5V AAA*2 |
|
Typical battery life |
12 h with laser off |
